New Energy Car Electrical Safety Analyzer ISO 6469 For Hybrid Vehicles

Product Details:

Place of Origin: China
Brand Name: Sinuo
Certification: Calibration Certificate (Cost Additional)
Model Number: SNE6804A

Payment & Shipping Terms:

Minimum Order Quantity: 1
Price: Customized
Packaging Details: Plywood Case
Delivery Time: 30 days
Payment Terms: T/T
Supply Ability: 30 sets/month
Contact Now

Detail Information

Applied Standard: ISO 6469, Etc Test Objects: Electric/hybrid Vehicles
Display Method: 10.2-inch LCD Storage Method: USB
Potential Equalization Rated Output: 32a/600mΩ/8vdc Max. Charging Socket Insulation Output: 1kvdc/10gΩ
EV IR Measurement Range: 0.20-100.00mΩ EV IR Measurement Accuracy: ± (2% Of Reading Value + 2 Words)
High Light:

USB Electrical Safety Analyzer


10.2 inch LCD Electrical Safety Analyzer


ISO 6469 ev test equipment

Product Description



ISO 6469 Electrical Safety Analyzer for Electrical and Hybrid Vehicles


Complied Standards & Clauses


ISO 6469-1:2019 Electrically propelled road vehicles — Safety specifications — Part 1: Rechargeable energy storage system (RESS)


IEC 62196:2020 Plugs, socket-outlets, vehicle connectors and vehicle inlets-Conductive charging of electric vehicles



Equipment Overview


With the rapid development of new energy vehicles, the automotive aftermarket that stands behind the car companies has also attracted much attention. Car-related services that occur in the process of using new energy vehicles, such as repairs and maintenance, vehicle modification, and vehicle inspections, need to be tested for the safety of the vehicle again. For 4S shops, vehicle management offices and other places of use, we have specially developed the SNE 68 series of special safety analyzers for new energy vehicles.


Test Project

1. Potential equalization test:

The resistance value of the connection between all exposed conductive shells and the electric platform; the resistance between any two exposed conductive shells that can be touched at the same time.


2. Insulation resistance of the charging socket:

Whether the insulation resistance between the phase line terminals of the vehicle's AC charging socket or the positive and negative terminals of the DC charging socket and the electric platform can meet the requirements.


3. Vehicle insulation resistance test:

It is used to detect whether the vehicle-level insulation resistance can meet the requirements. It is divided into the insulation resistance of the circuit containing the B-level voltage power supply and the insulation resistance of the B-level voltage load without the power supply.


4. Insulation detection function verification:

The vehicle has an insulation resistance detection function. This item is used to detect whether the vehicle can normally transmit an alarm signal to the driver when the vehicle's insulation fails.


Functions and Features

1. Multifunctional integration: potential equalization, charging socket insulation, vehicle insulation (battery pack insulation), insulation resistance monitoring and testing;


2. Support vehicle VIN scanning function, can automatically call corresponding test parameters and steps, and store and print test data in association: data storage, query filtering, information management;


3. Perfect protection: The device will not start high voltage detection if the plug is not plugged in; pulling out the plug in the detection state will cut off the power supply to the socket:


4. Scan code start, button start, remote control starts and other start methods to meet the needs of different customers.


5. Using 4U standard size, 10.1-inch touch screen, the operation is more concise;


6. More channel tests can be customized as needed.


Main Configuration

Standards applied ISO 6469, IEC 62196, etc
Model SNE6804A
Display method 10.2-inch LCD
Testing objects Electric/hybrid vehicles
Storage method USB
Alarm method Sound and light alarm: buzzer, indicator light, three-color warning light
Standard configuration function External warning light Standard three-color warning light
Remote switch function Standard remote control foot switch, external start signal can be connected
Switch output interface Qualified, unqualified, testing
Dedicated detection software New energy vehicle special detection software
Printer interface Can be equipped with label printer or sticker printer as standard
Barcode gun interface VIN and main part number identification, bar code, two-dimensional code
Other interfaces USB port, network port, etc.
Other Customizable

Technical Parameters


Potential equalization Rated output 32A/600mΩ/8VDC max.
Dc current output

Range: 3.00~32.00a

Resolution: 0.01a

Accuracy: ± (1%×reading value+0.2a)
Resistance measurement range 0.0-600.0mΩ
Resistance measurement accuracy ± (1%×reading value+3mΩ)
Testing time

Range: (0.0,0.1~999.9) s

Resolution: 0.01s

Accuracy: ± (0.1%×setting value+0.05s)
Charging socket insulation Rated output 1kvdc/10gΩ
Dc voltage output Range: (100~1000) vdc
Resolution: 1v
Accuracy: ± (1%×setting value+2v)
Insulation resistance measurement Range: 0.050mΩ~10gΩ
Resolution: 0.001mΩ/0.01mΩ/0.1mΩ/1mΩ
Resistance judgment error (100-499) v, 0.050mΩ~2.000gΩ, ± (5% reading value + 2 words)
(500-1000) v, 0.050~999.9mΩ, ± (2%×reading value+2 words)
1.000g~10.00gΩ, government (5%×setting value+2 words)
Ramp up time Range: (0.1~999.9) s
Delay judgment time Range: (0.3~999.9) s
Slow down time Range: (0.0~999.9) s
Testing time Range: (0.0~999.9) s
Discharge time No load ≤50ms, capacitive ≤200ms
Charging lower limit current (0.0~3.5)ua
Entire vehicle insulation resistance Insulation resistance setting range

Upper limit: 0 (closed)


Lower limit: 0.00-100.00mΩ
Insulation resistance measurement range 0.20-100.00mΩ
Insulation resistance measurement accuracy ± (2% of reading value + 2 words)
Test time setting range 0.0-999.9s 0.0=continuous output
Insulation detection Test time setting range 0.0-999.9s 0.0=continuous output
Test time accuracy ± (0.1% setting value+0.05s)
Judgment type Whether the car insulation detection is normal and alarms
