Multi Channel Electrical Safety Testing Equipment AC DC Power Analyzer LCD Display

Product Details:

Place of Origin: China
Brand Name: Sinuo
Certification: Calibration Certificate (Cost Additional)
Model Number: SNI3500

Payment & Shipping Terms:

Minimum Order Quantity: 1
Price: Customized
Packaging Details: Carton Box
Delivery Time: 30 days
Payment Terms: T/T
Supply Ability: 30 sets/month
Contact Now

Detail Information

Test Channel: 1-6 Channel Display Method: LCD
AD Sampling Rate: 100kS/s Data Update Cycle: 100m/200m/500m/1/2/5[S]
Crest Factor: 3.0 Interface Configuration: RS232/USB
Signal Bandwidth: 0.5Hz~100kH Harmonic Analysis: Yes
High Light:

WH AH Electrical Safety Testing Equipment

,

LCD Display Electrical Safety Testing Equipment

,

RS232 ac dc power analyzer

Product Description





 Multi-Channel High-Precision Power Analyzer



Equipment Overview




1. Test channel: 1-6 channels are optional



2. Both AC and DC are used to measure AC signals as well as DC signals.



3. Support WH and AH points to meet different test requirements.



4. It Can carry out efficiency measurement, input and output synchronous measurement, single-phase input/three-phase input or three-phase input/three-phase output



Technical Parameters




Model SNI3500X
Display method LCD
Test channel 1-6 channel for choices
Main measurement parameters Voltage RMS Urms, DC voltage Udc, Voltage average Mean, AC voltage Uac, Current RMS Irms, DC current Idc, AC current lac, active power P, reactive power Q, apparent power S, power factor PF, phase Angle φ, voltage frequency fU, current frequency fl, positive and negative peak voltage U+pk/U-pk, positive and negative peak current I+pk/I-pk, voltage crest factor CfU, current crest factor Cfl, electric energy Wh, current integral Ah, integration time, average active power AVP, average current AVI, total distortion THD
Simultaneous measurement of RMS/DC/AC Yes
AD sampling rate, data update cycle

100kS/s

100m/200m/500m/1/2/5[S]

Full-scale crest factor 3.0
Line filter, frequency filter OFF or ON (Frequency is 500Hz,5.5kHz)
Interface configuration (standard) RS232/USB
Input signal bandwidth, sampling frequency DC, 0.5Hz~100kHz, 100kS/s
Test function Harmonic analysis (FFT) Yes
Line filtering, frequency filtering OFF,500Hz,5.5kHz
Rated capacity Rated range of voltage and current 15/30/60/150/300/600[V],100m/200m/0.5/1/10/20[A]
Test range Current measurement range 0.50~9999~6000v, 0.50mA--20[A]
Power, power factor range (75.0mW~12kW)*3,±(0.001~1.000)
Frequency measurement range and accuracy DC, 0.5Hz~100kHz, ±0.1%x display value
Harmonic measurement 11Hz~600Hz, 1~50times
Electric energy, electric energy timing range 0~9999MWh,999h59m59s
Test accuracy (Voltage/Current/Power)

DC: ± (0.1% of reading + 0.2% of range)

0.5Hz≤f<45Hz: ± (0.1% of reading + 0.2% of range)

45Hz≤f≤66Hz: ± (0.1% of reading + 0.1% of range)

66Hz<f≤1kHz: ± (0.1% of reading + 0.2% of range)

1kHz<f≤10kHz: ± (0.07% of reading xf+0.3% of range)

10kHz<f≤100kHz: ± (0.5% of reading + 0.5% of range)
