Good price IEC 600068-2-30 Humidity Temperature Environment Test Chamber 225L online

IEC 600068-2-30 Humidity Temperature Environment Test Chamber 225L

Product Details:

Place of Origin: China
Brand Name: Sinuo
Certification: Calibration Certificate (Cost Additional)
Model Number: SN881-225L

Payment & Shipping Terms:

Minimum Order Quantity: 1
Price: Customized
Packaging Details: Plywood Case
Delivery Time: 30 days
Payment Terms: T/T
Supply Ability: 30 sets/month
Contact Now

Detail Information

Applied Standard: IEC60068-2-30, Etc. Working Volum: 225L
Inner Chamber Size: 600×500×750mm Inner Chamber Material: SUS304# Stainless Steel Plates
Heating Rate: ≧2-3°C/min Cooling Rate: ≧0.7-1°C/min
Humidity Range: (20 ~ 98) % RH Humidity Deviation: ±3%RH
High Light:

SUS304 stability chamber temperature and humidity

,

225L stability chamber temperature and humidity

,

600×500×750mm environmental testing chamber

Product Description





IEC 600068-2-30 Humidity Temperature Environment Test Chamber 225L



Complied Standards & Clauses


IEC60068-2-1:2007 “Environmental Testing-Part 2-1: Tests-Test A: Cold, IDT”



IEC60068-2-2:2007 “Environmental Testing-Part 2-1: Tests- Test B-Dry heat, IDT”



IEC60068-2-30:2005 “Environmental Testing-Part 2-30: Tests-Test Db: Damp heat, cyclic (12h+12h cycle), IDT ”



IEC60068-2-78:2012 “Environmental Testing-Part 2-78: Tests-Test Cab: Damp heat, steady state, IDT”



Technical Parameters


Control & Operation PLC and touch screen intelligent control system
Chamber Size (Optional) Inner Size External Size
225L, WDH=600×500×750mm WDH=1150×970×1900mm
Temperature Range (Optional)

A: -20~150℃;

B: -40~150℃;

C: -70~150℃

Humidity Range 20%~98%RH
Temperature Resolution 0.1℃
Temperature Fluctuation ±0.5℃
Temperature Uniformity ±2℃
Humidity Deviation ±3%RH
Heating Rate ≧2-3°C/min
Cooling Rate ≧0.7-1°C/min



Equipment Overview


Samples and Restrictions: It is used for cold, heat, humidity and dryness testing of raw materials and devices such as electronics, electricians, electrical appliances, plastics, etc.



Application: It is used for cold, heat, humidity and dryness testing of raw materials and devices such as electronics, electricians, electrical appliances, plastics, etc. The purpose is to confirm the products reliability of storage and transportation under high and low temperature alternating heat and humidity.

IEC 600068-2-30 Humidity Temperature Environment Test Chamber 225L 0

Test Principle: The heating, humidification and refrigeration system are used to control and change the ambient temperature and humidity in the chamber, to simulate the ambient temperature and humidity and alternating procedures required by the product.



Structure:

This machine adopts a closed chamber structure with the following features:

A. It has an extremely wide temperature and humidity control range to meet the various needs of users.



B. It adopts a unique balanced temperature adjustment and humidity control mode to adjust the ideal temperature and humidity environment. The heating and humidification capability are stable and balanced, and the temperature and humidity control are high-precision and high-stability.



C. Automatic selection of refrigeration circuit: The automatic control device has the ability of automatically starting the running refrigeration circuit according to the set value of temperature, can start the cooling directly under the high temperature state. The refrigeration adopts the air-cooled condensing unit with fully enclosed compressor (imported).



D. The door is equipped with a observation window, which is convenient for observing the test state of the test sample.



Questions & Answers


Q: What temperature range can you offer?
A: We can customize the temperature range according to client's requirements, such as 0~
150℃, -20 ~ 150℃; - 40 ~ 150 ℃; - 70 ~ 150 ℃, etc.



Q: What are the size options for this device?
A: The size of the equipment can be customized according to client's specific requirements. Our standard chamber volumes are 80L, 150L, 225L, 408L, 800L,1000L.



IEC 600068-2-30 Humidity Temperature Environment Test Chamber 225L 1
