Good price Benchtop Xenon Arc Lamp Artificial Environmental Test Chamber SAE J2527 online

Benchtop Xenon Arc Lamp Artificial Environmental Test Chamber SAE J2527

Product Details:

Place of Origin: China
Brand Name: Sinuo
Certification: Calibration Certificate (Cost Additional)
Model Number: SN884A

Payment & Shipping Terms:

Minimum Order Quantity: 1
Price: Customized
Packaging Details: Plywood case
Delivery Time: 30 days
Payment Terms: T/T
Supply Ability: 20 sets/month
Contact Now

Detail Information

Applied Standard: ASTM G155 And Etc. Light Source: 1.8KW Air-cooled Xenon Lamp
Lamp Life: 1500 Hours Filter Type: UV Filter
Effective Exposure Area: 1000cm² Irradiance Monitoring Method: 340nm Or 420nm And 300nm-400nm
Blackboard Temperature: RT+30℃~80℃ Warranty Pperiod: One Year
High Light:

ASTM G155 benchtop environmental test chamber

,

evse Environmental Test Chamber

,

evse electric vehicle environmental test chamber

Product Description





SAE J2527 Benchtop Xenon Arc Lamp Artificial Environmental Test Chamber





Complied Standards & Clauses


Automobile parts industry: SAEJ2412, SAEJ2527



Coating industry: GB/T 1865-2009 (based on ISO 11341:2004), ISO11341


Rubber and plastic industry: ISO4892-2, ASTM D2565, GB/T16422.2-1999(based on ISO 4892-2:1994)

Textile industry: GB/T8427(based on ISO 105 B02:1994), AATCC16E, AATCC169(1), ISO 105B-06, ISO 105B-02

Material industry: ASTM G155, ASTM D6551

Equipment Overview

This is a small, simple and economical xenon lamp aging test chamber. It adopts a low-power air-cooled xenon lamp and uses a mirror reflection system to ensure that the radiation energy in the studio is large enough and evenly distributed. It comes standard with a UV filter that allows the passage of UV light below the cut-off point of natural sunlight (equivalent to un-atmospheric sunlight) to provide faster and harsher test conditions for accelerated weathering in artificial climates.

The operator can arbitrarily set various parameters (irradiation energy, irradiation time, blackboard temperature, etc.) required for the test through the man-machine interface, and can check the operating status of the machine at any time. The operating parameters during the test can be directly download to PC through the USB interface.



Technical Parameters


Light source 1.8KW imported air-cooled xenon lamp or 1.8KW domestic xenon lamp
Lamp life Normal service life is about 1500 hours
Filter UV filter (can also choose daylight filter or window glass filter)
Effective exposure area 1000cm² (9 samples of 150x70mm can be placed at a time)
Irradiance monitoring method 340nm or 420nm and 300nm-400nm
Irradiance setting range

Domestic lamps:

30W/m²-100W/m² (300nm~400nm)

or 0.3W/m²~0.8W/m² (@340nm)

or 0.5W/m² ~1.5W/m² (@ 420nm)



Imported tube:

30W/m²-120W/m² (300nm~400nm)

or 0.3W/m²~1.0W/m² (@340nm)

or 0.5W/m²~1.8W/m² (@ 420nm)

Blackboard temperature setting range Room temperature +30℃~80℃
Inner/outer box material

All stainless-steel plate 304

Equipment dimensions 950x530x540mm (length x width x height)
Equipment net weight 93Kg (130Kg in plywood case)
Power supply 220V, 50 or 60HZ (choose one of the two): maximum current 16A
Maximum power of the whole machine 2.6KW


Equipment Principle


Artificial weathering or artificial exposure of the coating or polymer material with xenon arc light filtered by the filter, the purpose is to make the coating or polymer material after a certain exposure radiation energy, make the selected A certain degree of change in properties, or exposure to radiant energy required to age a sample to a certain degree. The properties selected for monitoring should be the properties of the material that are important in practical applications. The properties of the exposed material can be compared to the properties of a similarly prepared unexposed material (control sample), or to a simultaneously exposed material with known properties (reference sample).



Benchtop Xenon Arc Lamp Artificial Environmental Test Chamber SAE J2527 0



Typical application


This instrument uses a UV filter that allows the passage of UV light below the cut-off point of natural sunlight (equivalent to un-atmospheric sunlight), simulating the full spectrum of sunlight in the best possible way. And by properly controlling the temperature, the damage effect of sunlight and temperature on polymer materials can be fully obtained (material aging includes fading, loss of light, strength reduction, cracking, peeling, chalking and oxidation, etc.). In a matter of days or weeks, this test chamber is capable of reproducing damage from months or years of outdoor environments. It is the most economical, compact, simple, reliable and easy-to-use xenon lamp aging test chamber, which is widely used in the estimation and evaluation of material life in paint coatings, automobiles, plastic products, wood products, rubber and other industries.



Benchtop Xenon Arc Lamp Artificial Environmental Test Chamber SAE J2527 1
