5V 300A Lithium-ion Batteries Performance Test Battery Cell Testing Equipment

5V 300A Lithium-ion Batteries Performance Test Battery Cell Testing Equipment

Brand Name:	Sinuo
Model Number:	SN552-5V300A
MOQ:	1
Price:	Customized
Payment Terms:	T/T
Supply Ability:	1 sets/month

Detail Information

Product Description

Detail Information

Place of Origin:

China

Certification:

Calibration Certificate (Cost Additional)

Resolution:

1000mS

Stability:

±0.1%FS

Maximum Output Current:

±300A

Minimum Output Current:

±600mA

Charging Voltage Range:

0V-5V

Discharge Voltage Range:

1.3V-5V

Discharge Response Time:

≤ 20ms

Charging Response Time:

≤ 20ms

Packaging Details:

Other

Supply Ability:

1 sets/month

Highlight:

300A Lithium-ion Batteries Performance Test

5V Lithium-ion Batteries Performance Test

Battery Cell Testing Equipment

Product Description

5V 300A Lithium-ion Batteries Performance Test Battery Cell Testing Equipment

Equipment Overview

The equipment is mainly composed of upper computer, intermediate computer, DC/AC module, DC/DC module, lower computer, data acquisition and processing system, etc., and can

real-time collection of voltage, current, capacity, energy and other information of each single battery. Optional support for battery temperature data collection. The collected data is stored in a specially designed database and provides various data statistics, analysis and report generation functions.

System architecture diagram, as shown below:

5V 300A Lithium-ion Batteries Performance Test Battery Cell Testing Equipment 0

Technical Parameters

Model		SN552-5V300A
Number of main channels		1 channel/set
Main channel test abort condition		Time, voltage, current, capacity, etc.
Main channel voltage	Charging voltage range	0V-5V
	Discharge voltage range	1.3V-5V (1.3V is the device port voltage)
	Accuracy	±(0.05%RD+0.05%FS)
	Resolution	0.1mV
Main channel current	Maximum output current	±300A
	Minimum output current	±600mA
	Accuracy	±(0.05%RD+0.05%FS)
	Resolution	0.1mA
	Current start response time	≤20ms (≤10ms optional)
Time	Resolution	1000mS
Power	Output power	Single channel continuous operation maximum power 1200W
Power	Stability	±0.1%FS
The highest efficiency of charging and discharging		75%
Feed network	Harmonic	≤3%
Feed network	Power factor	≥0.99

Charging response time ≤ 20ms	Discharge response time ≤ 20ms

Charging switching and discharging switching time ≤ 40ms	Discharge switching charge switching time ≤ 40ms

CC-CV current curve
