Walk-in Constant Temperature and Humidity Environmental Test Chamber

Walk-in Constant Temperature and Humidity Environmental Test Chamber

Brand Name:	Sinuo
Model Number:	SN886-12m³
MOQ:	1
Price:	Customized
Payment Terms:	T/T
Supply Ability:	10 sets/month

Detail Information

Product Description

Detail Information

Place of Origin:

China

Certification:

Calibration Certificate (Cost Additional)

Applied Standard:

IEC60068-2-78, Etc.

Effective Volume:

12m³

Temperature Range:

-40°～ 150℃

Temperature Fluctuation:

±2℃

Humidity Range:

20%RH～95%RH

Humidity Fluctuation:

±2.0%RH

Heating Rate:

≦3.0℃/min (non-linear, No Load)

Cooling Rate:

Average 1.0℃/min (non-linear, No Load)

Packaging Details:

Other

Supply Ability:

10 sets/month

Highlight:

Walk In Environmental Test Chamber

Constant Temperature Environmental Test Chamber

Humidity Environmental Test Chamber

Product Description

Walk-in Constant Temperature and Humidity Environmental Test Chamber

Complied Standards & Clauses

IEC 60068-2-1 Test A: Low-temperature test method.

IEC 60068-2-2 Test B: High-temperature test method.

IEC 60068-2-3 Test Ca: Constant damp heat test method.

IEC 60068-2-30 test Db: alternating damp heat test method.

Equipment Overview

This walk-in chamber provides precise, programmable control of both temperature and humidity, making it ideal for environmental simulation testing of large components, EV systems, aerospace parts, electronics, and industrial equipment.Designed for high-precision environmental testing, this spacious 12m³ walk-in chamber simulates extreme temperature and humidity conditions to ensure product durability and reliability. Ideal for EV components, electronics, aerospace, and industrial materials testing.

Technical Parameters

Volume and dimensions
Effective volume	12m³
Inner chamber size	3000 mm2000 mm2000mm(WHD)
Outer chamber size	Approximately 3700 mm2200 mm2300 mm(WHD) Warm reminder: Please refer to the three views of the final design for external dimensions.
Container size	The inner dimensions of the 40HQ container are 12.032m (L)2.352m (W)2.69m(H) The door is 2.55M high (it will be extra wide after being packed with wooden boxes)
Performance
Cooling method	Water cooling
Temperature range	-40°～ 150℃
Humidity range	20%RH～95%RH
Temperature/humidity fluctuation	±2℃/±2.0%RH
Temperature analysis accuracy	0.01℃
Humidity analysis accuracy	0.01RH
Temperature uniformity	≤2℃
Humidity uniformity	< 75%RH:±3%RH >75%RH±5%RH
Heating rate	≦3.0℃/min (non-linear, no load)
Cooling rate	Average 1.0℃/min (non-linear, no load)
Load condition	No load

Details
