Constant Temperature and Humidity Chamber Humidity Cycling Test Chamber

Name: Constant Temperature and Humidity Chamber Humidity Cycling Test Chamber
Brand: Sinuo Testing Equipment Co. , Limited
SKU: SN881-G1000
Availability: InStock

Brand Name:	Sinuo
Model Number:	SN881-G1000
MOQ:	1
Payment Terms:	T/T
Supply Ability:	10 Sets Per Month

Detail Information

Product Description

Detail Information

Place of Origin:

China

Certification:

Calibration Certificate (Cost Additional)

Temperature Range:

+15°C ~ +90°C

Humidity Range:

20% ~ 98% RH

Temperature Deviation:

≤±2.0℃

Humidity Deviation:

≤±3%

Internal Dimensions:

1000 × 1000 × 1000 Mm

External Dimensions:

1280 × 2150 × 1950 Mm

Heating Time:

≥ 2–3°C/min (no Load)

Cooling Time:

≥ 1°C/min (no Load)

Packaging Details:

Export packing

Supply Ability:

10 Sets Per Month

Product Description

Constant Temperature and Humidity Chamber Humidity Cycling Test Chamber

Complied Standards & Clauses

IEC60068-2-1:2007 “Environmental Testing-Part 2-1: Tests-Test A: Cold, IDT”

IEC60068-2-2:2007 “Environmental Testing-Part 2-1: Tests- Test B-Dry heat, IDT”

IEC60068-2-78:2012 “Environmental Testing-Part 2-78: Tests-Test Cab: Damp heat, steady state, IDT”

IEC60068-2-30:2005 “Environmental Testing-Part 2-30: Tests-Test Db: Damp heat, cyclic (12h+12h cycle), IDT”

Product Overview

The SN881-G1000 Temperature and Humidity Test Chamber is specifically engineered to simulate a wide range of temperature and humidity environments for testing electronics, plastics, electrical appliances, and other industrial materials. With its spacious 1000L capacity and precise control system, this chamber ensures stable and repeatable conditions for product reliability, durability, and aging tests — essential for quality assurance, R&D, and compliance testing.

Technical Parameters

Item	Specification
Model	SN881-G1000
Internal Dimensions	1000 × 1000 × 1000 mm (W × D × H)
External Dimensions	1280 × 2150 × 1950 mm
Temperature Range	+15°C ~ +90°C
Humidity Range	20% ~ 98% RH
Temperature Fluctuation	±0.5°C
Temperature Deviation	≤ ±2.0°C
Humidity Fluctuation	≤ 2.5% RH
Humidity Deviation	≤ ±3% RH
Heating Rate	≥ 2–3°C/min (no load)
Cooling Rate	≥ 1°C/min (no load)
Noise Level	≤ 70 dB(A) (measured at 1m distance, in soundproof environment)
Control System	PLC + 7” Color Touch Screen, Programmable Controller
Temperature Sensor	PT100 Platinum Resistance Sensor
Humidity Sensor	PT100 Platinum Resistance Sensor
Compressor	TECUMSEH (France), Fully-Enclosed, Air-Cooled
Refrigeration System	Single-stage mechanical compression, air-cooled
Heating Method	SSR (Solid State Relay) Pulse Modulation, Heating Power ≈ 4KW
Observation Window	400 × 600 mm, 3-layer vacuum tempered glass with electric heating anti-fogging
Insulation	100mm Polyurethane Foam (Cabinet and Door)
Lead Hole	Ø50mm with rubber plug (1 piece, customizable location/quantity)
Power Supply	AC380V, 50Hz, Three-phase Four-wire + Ground
Power Capacity	Approx. 7 kW
Maximum Current	18A
Protection Devices	Over-temp, overload, compressor overheat, short-circuit, leakage, dry heating, etc.
Data Interface	RS232 / RS485 (optional USB output / printer)
Program Memory	120 programs × 100 segments, graphical interface with curve display
Standard Compliance	IEC60068-2-1 / 2-2 / 2-30 / 2-78

Details
